Thermal Camera TC3231

Megger TC3231 offers a professional 32 x 31 pixel infrared thermometer with a 2.2" (55.88mm) color TFT LCD display. Fast, accurate readings are possible; covers a wide range of surface temperature measurements. The product combines the convenience of an infrared thermometer with the visual advantage of a thermal imager providing a troubleshooting camera with an infrared heat map. The TC3231 has a range of selectable thermal image color palette display options as well as user defined high/low temperature alarms.

There is also an easy-to-use image blending feature; the camera takes a flattened visible, non-infrared image along with a full infrared image. The 2 images are then blended and can be adjusted from 0 to 100%. This makes it much easier to identify problems and locate them. In addition to measuring the temperature of the central spot, the camera also provides simultaneous tracking of hot and cold spots, and the resulting values ​​and location are continuously updated on the display. Up to 6,000 images can be stored on the supplied micro SD memory card, which can be downloaded to a PC via USB in BMP file format. An SD card adapter is also provided for transferring files to a PC
